PARS-BIM : ARCHITECTURE TOOLS 1.0.0

Built on years of hands-on modelling experience, this plugin is designed to dramatically speed up your workflow while saving both time and costs. With powerful automation tools and smart features, it takes the repetitive, time-consuming tasks out of your hands—so you can focus on design.

Here’s what it can do for you

1. Automatic Modelling from Linked CAD Files

Easily convert Autodesk® AutoCAD® drawings into Autodesk® Revit® models. The plugin automatically detects walls, doors, and windows based on CAD layers—no need to manually draw wall centrelines. It even recognizes wall thicknesses, places the correct types, or creates new wall types for you.

Doors and windows can also be automatically placed, either by detecting their dimensions or replacing AutoCAD blocks. While every CAD file is different and some manual tweaks may be needed, this feature saves enormous amounts of time at the start of every project.

2. Smart Family Placement

Place Revit families directly based on CAD block coordinates in just a few clicks. You can place them

On the floor
On the main ceiling
On the ceiling of a linked Revit file
This is especially useful for MEP equipment and ceiling-mounted elements such as lighting fixtures, sprinklers, detectors, and more—reducing what used to take hours into minutes.

3. Quick Room Finishing & Ceilings

Apply wall finishes, flooring, and even false ceilings to all rooms across multiple floors in just a few clicks. What normally takes days of manual work can now be done instantly.

4. Room & Ceiling Legends with One Click

Generate detailed, color-coded legends that display room number, name, and area—something Revit doesn’t provide out of the box.

You can also create legends showing different false ceiling heights with colour coding, giving you clear, instant visual feedback on ceiling levels across the project.

5. Batch View Template Assignment

Need 10 view templates per floor across 10 floors? That’s 100 tedious manual steps—duplicating, renaming, and assigning templates. With this plugin, it’s done in seconds.

6. Fast Level Creation

Levels are simple, but repetitive. With our optimized tool, you can define all required levels faster than ever.

7. Smart Sheet Management

Delete or reorder sheets without disrupting numbering. Add or remove sheets anywhere in the index—numbers update automatically.

8. Excel-to-Revit Sheet Import

Skip manual entry—create a full sheet list from an Excel file with one click.

9. Auto-Dimensioning for Large Projects

Generate all necessary dimensions—grid spacing, window widths, wall lengths—with just a few clicks, no matter the project size.

10. Advanced Filtering & Selection

Easily filter and select elements

Choose only elements visible in the active view based on your filters.
Create filters for pipes and ducts by system type.
Restrict selections to specific categories.
Select only horizontal pipes instantly.

11. Integrated Clash Detection Reporting

View graphical clash reports directly in Revit—no more copying Element IDs from Navisworks or hunting for views.

12. View Template Export

Easily export a perfect view template from one project and apply it to another—saving you time and ensuring consistency.

Compatible with
Autodesk Revit
Version: 2026 , 2025 , 2024
