Circuit Calculator v5.7
Circuit Calculator v5.7 | Android | 1.96 MB
"Circuit Calculator" is an electronics design tool for engineers. 170+ circuits for design, 50+ electronics calculators, 20+ Application Notes, Logic Solver. Convenience, visibility and ability to find an optimal solution in minimum time. Simple user interface, small size, smart tool.
This electronics design tool is designed by an engineer for engineers and is able to save you a lot of time!
• Amplifiers;
• Variable Gain Amplifiers;
• Drivers;
• Mathematical Operations;
• Current Sources and Receivers;
• Impedance Converters;
• Low-pass, High-pass, Band-pass, Band-stop, All-pass Filters;
• Impedance Matching;
• Power Circuits;
• Switching-Mode Power Supply Modules with small-signal analysis;
• Control Loop Compensation;
• Others Passive and Active Circuits;
• Reverse: calculation of circuit parameters at known values of its components if it is possible;
• Logic Solver, from 2 to 6 inputs;
• Auxiliary electronics-specific tools;
• Application Notes;
System Requirements:
Requirements: Android 4.0.3+
Home Page - https://play.google.com/store/apps/details?id=com.vdv.circuitcalculator&hl=en
